- 【Professional, Reliable】S.h.i.p. from. U.S. Ware-house. Model: DS-2DE4425IW-DE, This 4MP PTZ Camera is International Version, support upgrade firmware, support PoE (802.3at), plug and play with Hik-vision NVR. With an IP66-rated design, this camera is designed to withstand inclement weather! We provide 2-year warranty and life-t-ime support for users. If you have any questions, please feel free to contact us.
- 【High quality 4MP with DarkFighter】The PTZ network camera uses the latest 1/2.5'' progressive scan CMOS with a resolution of up to 2560 × 1440@30 fps. Excellent low-light performance via powered-by-DarkFighter technology, illumination down to 0.005 Lux. Expansive night view with up to 328ft(100m) IR distance. Clear imaging against strong backlight due to 120dB WDR technology. Effective H.265 encoding, saves storage space and bitrate to ensure smooth video real-time streaming and playback.
- 【25X Optical Zoom】This 4MP PTZ Camera equipped with a 4.8~120mm motorized lens, supports 25x optical zoom and 16x digital zoom, allowing for closer viewing of subjects in expansive areas, monitoring home and business security at all times. The 4MP PTZ IP Camera Movement Range (Pan) 360° endless, Movement Range (Tilt) from -15° to 90° (auto-flip). Pan and tilt ability enable the camera to monitor zones of interest.
- 【Smart VCA Detection】Built-in Video Content Analysis(VCA) algorithmfor more efficient monitoring as well as more effective perimeter protection, such as line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection. Also support Smart Record: ANR (Automatic Network Replenishment), Dual-VCA.
- 【Efficient H.265 Compression & Multiple Storage Options】The latest H.265 technology compresses your video without sacrificing any Ultra HD video quality, it reduces bandwidth by up to 75% over traditional H.264 compression, which not only transmits clearer, smoother video, but also saves up to 75% of disk storage space. Video can be saved in Micro SD card (Built-in memory card slot, up to 256 GB), Hik-vision NVR or NAS, FTP server.
Camera Module
Image Sensor: 1/2.5" progressive scan CMOS
Min. Illumination: Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001Lux @(F1.6, AGC ON),0 Lux with IR
White Balance: Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
Digital Zoom: 16×
Privacy Mask: 24 programmable privacy masks
Focus Mode: Auto/Semi-automatic/Manual
WDR: 120 dB WDR (not supported by full frame rate)
Lens
FOV: Horizontal field of view: 59.5° to 2.6° (Wide-Tele),Vertical field of view: 35.7° to 1.5° (Wide-Tele),Diagonal field of view: 66.6 to 3.0° (Wide-Tele)
Zoom Speed: Approx. 3.6 s (optical lens, wide-tele)
Working Distance: 10 mm to 1500 mm (wide-tele)
Aperture Range: F1.6 to F3.5
Focal Length: 4.8 mm to 120 mm, 25× optical zoom
Image Enhancement: HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus
Interface
Audio Input/Output: 1-ch/1-ch
Network Interface: 1 RJ45 10 M/100 M Ethernet, PoE (802.3 at, class4)
PTZ
Movement Range (Pan): 360° endless
Movement Range (Tilt): From -15° to 90° (auto-flip)
Speed: Configurable, from 0.1°/s to 80°/s,Preset Speed: 80°/s
Proportional Zoom: Support
Presets: 300
Patrol Scan: 8 patrols, up to 32 presets for each patrol
Power-Off Memory: Support
Park Action: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PTZ Status Display: Support
Preset Freezing: Support
Scheduled Task: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux Output
General
Material: ADC 12, PC 10% GF
Dimensions: Φ 164.5 mm × 290 mm (Φ 6.48" × 11.42")
Weight: Approx. 2 kg (4.41 lb)
Power: 12 VDC, 2.0 A and PoE (802.3 at), 42.5 to 57 VDC, 0.6 A, class4; Max.: 18 W, including max. 7W for IR
